Air Motion
Key Features
Unparalleled by any product on the market, the Air Motion's incomparable form serves as a flagship product for the Air Series. Comprising three transducers, each loaded by an isometric conical horn.
A conical horn expansion rate has been utilised to provide solid radiation angles, resulting in tighter beam width control and constant directivity. These benefits allow for exceptionally balanced waveform transmission with greater definition.
Product Specifications
140 Hz - 20 kHz ±3 dB
LF: 106 dB 1W/1m, HMF: 108 dB 1W/1m
LF: 8 Ω, HMF: 8 Ω
LF: 500 W AES, HMF: 250 W AES
132 dB cont, 138 dB peak
1 x 12” LF, 1 x 8” MF, 1 x 1.5” HF compression driver
60°H x 50°V
2 x 4-pole speakON™ NL4
35.4 kg (78 lbs)
Fibreglass composite
Integral mounting system
Custom colours available upon request
