Arclite
Key Features
Designed for pairing with Arcline 218 and 118 subwoofers, Arclite operates as a two-way active, three-way arrayable point source loudspeaker. A true point source alternative to the Arcline 8, offering scalability with maximum output and coherence.
Tailored for audio integrators and sound engineers with a focus on touring. Guaranteeing predictable behaviour in the most challenging applications. An arrays dispersion and sound pressure levels can be configured precisely to best serve any demands.
Product Specifications
45 Hz - 18 kHz ±3 dB
MHF: 113 dB 1 W / 1 m LF: 98 dB 1 W / 1 m
LF: 8 Ω, MHF: 16 Ω
LF: 1000 W, MHF 190 W
133 dB Cont, 139 Peak
1 x 15” LF, 1 x 4” MF, 1 x 2.5” HF
35° H x 60° V (25° up - 35° down)
2 x 4-pole speakON™ NL4
44 kg (97 lbs)
15 mm birch plywood
Ground stack or suspended
Textured ‘TourCoat’ polyurea
