16-channel active progressive curvature WST® amplified by LA7.16/LA7.16i

45 Hz - 20 kHz

Full element: 155 dB ([L2_70])
First module: 147 dB ([L2_70])

Vertical : 10° progressive directivity pattern
Horizontal : 4 x Panflex modules 70°/110° or 90° asymmetric integrated cardioid or supercardioid patterns

LC: 4 × 12’’ neodymium cone drivers LF: 8 × 10’’ neodymium cone drivers HF: 8 × 3’’ neodymium diaphragm compression drivers

LC/LF: Bass-reflex, L-Vents HF: DOSC waveguide, Panflex™

LC/LF/HF : 8 Ω/8 Ω/8 Ω

1 x 37-point male connector (32 points used)

flush-fitting 4-point captive rigging system compatible with L2D

158 kg/348 lb

Premium grade Baltic beech and birch plywood

Coated steel grill
Acoustically neutral 3D fabric

High grade steel with anti-corrosion coating

Dark grey brown Pantone 426 C

IP55
