Nexus XL
Mind-blowing energy, enviable design
The XL is a dance-floor heavyweight, unparalleled in both design and efficiency.
Key Features
Single high power 21” transducer
Five resonant chambers
Very high efficiency
Fast transient response
Untold Performance, Refined Design Principles
The Nexus XL delivers untold levels of performance through refined design principles as well as embracing progressive styling with a streamlined trim. An alternative to the Nexus X, the XL is purposed for use with the Nexus Q upper enclosure.
High Efficiency, Minimal Resonance
Unimaginable levels of performance have been achieved through further refining of the five resonant chamber theory used in the infamous Stasys X. Impressive advancements create the perfect foundations for a breath-taking nightclub sound system.
Product Specifications
Frequency Response
30 Hz - 150 Hz ±3dB
Efficiency
104 dB 1W/1m (Measured in half space)
Crossover Points
Hi Pass 30 Hz - 24 dB/oct
Nominal Impedance
8 Ω
Power Handling
2000 W AES (AES2 - 1984 compliant)
Maximum Output
135 dB cont; 141 dB peak (Calculated)
Driver Configuration
1 x 21”
Dispersion
Array dependant
Connectors
2 x 4-pole speakON™
Weight
90 kg (198.4 lbs)
Finish
Textured ‘TourCoat’ polyurea
